ARBMAX D45 Drum Chipper – Power, Precision, and Performance
ARBMAX unveils the D45, a groundbreaking road-towable 18-inch chipper that redefines performance and versatility for tree professionals worldwide.
The largest capacity towable wood chipper under 3.5 tonnes. In the world of professional tree surgery, forestry, and land clearance, having a high-performance wood chipper is essential. The ARBMAX D45 Drum Chipper is a game-changer, delivering unmatched power, precision, and efficiency in the road towable <3.5T class. Whether you’re a professional arborist, contractor, or land manager, the D45 is designed to streamline your workflow and maximize productivity.
Unrivaled Chipping Power and Durability
At the heart of the ARBMAX D45 is its heavy-duty 4-pocket drum system, engineered for exceptional wood processing capabilities. This 18-inch drum chipper features oversized premium bearings and a robust design, ensuring long-lasting durability and reliability in high-intensity environments.
The feed area and chamber are lined with Hardox® 450, a wear-resistant steel that enhances longevity and withstands continuous heavy-duty use. The quick change knives and reversible anvil make maintenance on-site simple while reducing your costs and downtime.
High-Performance Engine & Efficiency
Efficiency is key in the forestry and arborist industry, and the ARBMAX D45 doesn’t disappoint. Equipped with a Stage 5 Caterpillar 100kW (134hp) diesel engine, this chipper delivers high torque and fuel efficiency, allowing operators to process large volumes of wood without excessive fuel consumption. The twin plate clutch ensures smooth engagement of the drum, while an 80-litre fuel tank provides extended operation time. The 80-litre hydraulic tank supports a dedicated oversized reversible oil cooler, maintaining optimal system performance and ensuring oil temperature are kept low.
The advanced hydraulic system ensures smooth and consistent feeding, making the chipping process both efficient and user-friendly. Specially configured chipping modes and a remote control crush feature allow operators to easily adapt to any material.
Customizable Chip Output for Versatile Applications
The D45 comes with an interchangeable Hardox® sizing screen, allowing users to adjust chip sizes based on project requirements. Whether you need fine wood chips for biomass applications or coarser output for landscaping and mulch, the D45 offers flexibility to meet diverse needs.
Designed for Professional Use – Mobility & Safety
As a road-towable drum chipper, the D45 provides excellent mobility, making it easy to transport between job sites. Safety is also a top priority, with intuitive control systems, safety intervals, acoustic alarms, and emergency stop features ensuring operator protection at all times. The D45 can operate in hand-feed mode or switch to machine feed mode at the push of a button.
Advanced Feed Chamber for Optimal Performance
The ARBMAX D45 is designed with a high-torque aggressive feed wheel, powered by a radial piston motor, ensuring strong and consistent material intake. The pivot-opening feed roller provides unrivalled access for maintenance, while the hydraulically controlled roller pressure adapts to different wood types.
Other key feed chamber features include:
- 200° drum access for easy maintenance.
- Bottom feed roller for optimum material grip.
- Crush feature to handle challenging material.
- Premium hydraulic motors for long-term reliability.
- Dual marine-grade multifunction controls for operator convenience.
Robust Chassis & Suspension for Stability
The ARBMAX D45 is built on a fully galvanised chassis, ensuring corrosion resistance and long-lasting durability. The wheeled chassis is equipped with two 1900kg heavy-duty leaf-sprung suspension axles, providing superior stability and smooth transportation across different terrains. Additionally, the three heavy-duty hydraulic stabilising legs offer extra support during operation, ensuring safety and precision.
Efficient Discharge System
The D45 features a Venturi discharge system with removable liners, allowing for efficient chip ejection and minimal clogging. The hydraulic control & adjustment ensures precise discharge positioning, improving workflow and operational efficiency. For those requiring extended reach, an optional 4.3m extended discharge chute is available, making it easy to load into high sided trailers.
Versatile Feed Chute for Different Loading Methods
The D45’s hydraulic feed chute is designed for maximum versatility, allowing loading by hand, crane, or machine. Integrated stop bars ensure safe hand-feeding, while the hydraulic operation makes it easy to adjust the chute’s position to accommodate various job requirements.
Optional Enhancements for Customization
The ARBMAX D45 can be further customized with additional options, including:
- Reversible engine cooling fan for enhanced cooling efficiency when working in dusty environments.
- Lighting package for improved visibility in low-light conditions.
- Different screen media to suit specific chipping needs.
- Extended chute with a 4.3m discharge height for larger-scale operations.
- Custom colours to match your company branding.
Why Choose the ARBMAX D45 Drum Chipper?
- Heavy-duty construction with Hardox® 450 lining for durability.
- Stage 5 Caterpillar diesel engine for optimal performance and fuel efficiency.
- Interchangeable sizing screen for customizable chip output.
- Road-towable design for mobility and versatility.
- Reliable hydraulic feed system for smooth operation.
- Advanced feed chamber with crush feature and pivot-opening feed roller.
- Fully galvanised chassis with heavy-duty suspension and stabilising legs.
- Venturi discharge system with hydraulic discharge chute adjustment and optional extended chute.
For professionals in tree surgery, forestry, and land management, investing in a premium wood chipper like the ARBMAX D45 means increased efficiency, reduced downtime, and superior chipping performance.
